1.Safety :
LFP(Lithium ion Phosphate) the highest safety
2.Up to 8 Series or Parallel :
Flexible to increase voltage capacity without any other equipments or settings
3.Cycle Life :
80% of initial capacity after 6000
4.WiFi & APP :
Integrated WiFi Modem OTA online upgrade convenient after-sales service
5.Installation :
Simple buckle fixing minimize the installation time and cost
| Product Parameters | |
Basic Parameters | CFE 7500 |
Nominal Voltage（V） | 51.2 |
Nominal Capacity（Wh） | 7680 |
Usable Capacity（Wh） | 6528 |
Dimension（mm） | 460*650*133 |
Weight（Kgs） | 65 |
Charge/Discharge Current（A） | 60(Recommend) |
60(Max) | |
100(Peak@15s) | |
Communication Port | CAN / RS485 |
Single string quantity（pcs） | 8 |
Charge Working Temperature（℃） | 0～45 |
DisCharge Working Temperature（℃） | -10～55 |
Storage Temperature（℃） | -10～35 |
Humidity | 0～95% (No Condensed Water) |
Altitude（m） | ＜2000 |
IP Rating | IP20 |
Warranty | 5 years |
Cycle life | 6000 |
Authentication Level | UN3480 & UKCA |
Cooling Type | Ambient Cooling |
Installation | Cabinet or Wall Mounting |
